RUBBER EXTRUSION

Rubber Seal D Section 3M Tape

Code:
X119BT
In Stock Low Stock Out Of Stock Please See Attributes 288
$17.83 inc GST
Increase value Decrease value


Qty Each (inc GST) Each
  • Specifications
  • Material and Finish
  • Features
  • Contact Us

  • Dimensions: 16 x 9.5mm
  • Service Temperature Range: -29°C to 70°C
  • Adhesive: BT Pressure Sensitive Adhesive (3M Acrylic Automotive Grade)
  • Manufacturing Origin: USA
  • Resistance to Ozone: Excellent
  • Resistance to Water Absorption: Excellent
  • Resistance to Sunlight Aging: Excellent
  • Resistance to Low Temperature: Excellent
  • Flammability Compliance: FMVSS 302 Horizontal Burn, UL50
  • Compression Rating: 25% compression for maximum performance
  • Environmental Compliance: ROHS Compliant
  • Bend Radius - Top: 127mm
  • Bend Radius - In: 89mm
  • Bend Radius - Out: 38.1mm

  • EPDM Sponge Rubber
  • BT Pressure Sensitive Adhesive (3M Acrylic Automotive Grade)

  • Excellent Environmental Resistance: With outstanding protection against ozone, water, sunlight, and low temperatures, this seal ensures long-lasting durability in harsh outdoor or marine environments.
  • High-Performance Adhesive: Features 3M automotive-grade acrylic tape for superior peel and shear strength, delivering a secure and airtight bond even under stress.
  • Wide Operating Temperature Range: Performs reliably from -29°C to 70°C, making it suitable for demanding applications across multiple industries.
  • Optimal Compression Seal: Designed for 25% compression, providing an effective, consistent seal against air, dust, and moisture.
  • Compliant & Safe: Meets FMVSS 302 and UL50 flammability standards and is ROHS compliant for safe use in regulated applications.
