Name: Accuride 75% Extension 35cm PR SS 65kg Load
Price: 201.28 NZD

Qty	Each (inc GST)	Each

End stops have been tested to 10 cycles with 400kg at 0.8m/s.
Load rating: up to 270 kg per pair
100 % extension
Slide height: 80 mm
Slide thickness: 26.5 mm
Side space for installation between the cabinet and the drawer: rail thickness 26.5 mm +0.2 mm to +0.5 mm
Maximum slide length: 1,000 mm
Two-way-travel slide with locking cams for intermediate member
Temperature -20 °C to 70 °C
Permitted mounting orientations: vertical mount
Not suitable for flat mounting
Corrosion resistant

Load rating up to 65kg per pair: Ideal for lighter-duty applications where space-saving access and reliable performance are essential.
75% extension: Provides controlled access to drawer contents for efficient loading, unloading, and workspace usability.
Vertical mount: Engineered for upright installations, ensuring reliable operation in vehicle and equipment cabinetry.
Stainless Steel: Corrosion-resistant for reliable performance in transport and industrial environments.
Shock and vibration tested: Engineered to withstand harsh conditions in transport, mining, and service vehicles.
RoHS compliant: Meets global environmental and safety standards for regulated industries.
