Name: Accuride Slide Tilt Drawer 100cm PR AL 65kg Load
Price: 995.36 NZD

Qty	Each (inc GST)	Each

End stops have been tested to 10 cycles with 400kg at 0.8m/s.
Load rating: up to 600 kg per pair
100 % extension
Slide height: 150 mm
Slide thickness: 38 mm
Side space for installation between the cabinet and the drawer: rail thickness 38 mm +0.2 mm to +0.5 mm
Maximum slide length: 1,500 mm
Two-way-travel slide with locking cams for intermediate member
Temperature -20 °C to 110 °C
Permitted mounting orientations: vertical mount
Not suitable for flat mounting
Corrosion resistant
Slides sold separately

Tilt and slide system: Allows safe and ergonomic access to overhead or elevated compartments, reducing strain and improving operator safety.
Load rating up to 65kg per pair: Ideal for lighter-duty applications where space-saving access and reliable performance are essential.
Vertical mount only: Engineered for upright installations, ensuring reliable operation in vehicle and equipment cabinetry.
Shock and vibration tested: Engineered to withstand harsh conditions in transport, mining, and service vehicles.
RoHS compliant: Meets global environmental and safety standards for regulated industries.
